TE 1028
TE1028 Mehrfach-Thermoelementschalttafel horizontal
Specifications
| Female multi panel | Thermocouple and RTD circuits |
| Contacts | Springloaded thermocouple contacts |
| Materials | Glass filled thermocouple body with original thermocouple material contacts |
| Front | Aluminium anodized for full corrosion protection |
| Temperature limit | Maximum 200°C |
| Body | Glass filled thermoplastic material |
| Design | Stainless steel bracket mounted with 2 screws |
| Molded barriers | Prevent short circuit |
| Identified | Scratchproof numbering |
| Accepts wires | From 0.2 mm to 2.0 mm |
| Colour code | According thermocouple |
Customisation possibilities
You can remark the customisation in your quote
| Productcode | TE 1028 |
|---|---|
| … |
