ML7090

ML7090 Multi spot resistance thermometer

Datasheet View Catalog

Specifications

Multi spot thermometer for bulk stored liquids, Food, Crude oil, Bitumen, Chemicals, Refined liquids
ConstructionFlexible convoluted gas-tight tube
MaterialStainless steel 316 standard, other materials possible
DesignGas and liquid tight. Screwed adjustable flange connection max. 2bar @100°C. Otherwise fixed welded to flange.
Tube diameter19mm standard, other diameters possible
Process connectionM25 or 1/2"BSPP standard, other threads possible
Temperature range-20 / +200°C
Cable3000mm weatherproof IP65 sealed cable standard, other lengths possible
TypeWirewound precision Pt100 detectors
Vibration proof superior class
AccuracyAccording to IEC 60751 Cl. B, A or AA
Junctionbox aluminium or stainless steel also possible in Ex version
Temperature transmitters, standard or Ex version. Please specify brand.
3Kg Anchor weight, Flange connection, other temperature limits and Ex version
This datasheet is purely indicative, build-up of model code may vary from this datasheet

Customisation possibilities

You can remark the customisation in your quote

Productcode ML7090
Number of sensors
L1 to Ln to specify
