B133 High temperature compression fitting

Datasheet View catalog


Material body and nutSteel 1.0715 zinc-plated
Material sealingCeramic, graphite or PTFE
Temperature ratingMax. 300°C
Working pressureMax. 1bar
Element diameter 6.0mmM16x1.5, M18x1.5 or 1/2"BSP (G1/2")
Element diameter 8.0mmM16x1.5
Element diameter 12mmM20x1.5 or 3/4"BSP (G3/4")
Element diameter 15mmM24x1.5, 1/2"BSP (G1/2") or 1"BSP (G1")
Element diameter 20mmM30x2
Element diameter 22mm1"BSP (G1")
Other proces connections

Customisation possibilities

You can remark the customisation in your quote

Productcode B133
